Thread: 6.5x55 velocity

  1. #1
    Member
    Join Date
    May 2012
    Location
    Up north
    Posts
    245

    6.5x55 velocity

    I'm having trouble developing a load for my 6.5x55, I am after a bit more velocity I believe I am only getting around 2500 fps and am already getting stiff bolt lift and extractor marks if I go up .5grain. The rifle is a ruger m77 with 22inch barrel I would have thought 2750 should be well within reach. This velocity is figured from what the books say I should be getting with the powder charge and from a proven trajectory. Crony is on the Xmas list.
    The load is 140gr sst, 41grns AR2209 this is well under book max, I have three areas I'm looking at.

    I seam to get really dirty necks, I have heard this can be from underloading which doesn't seam to make sense, I'm just a bit confused by this if the brass is showing max preassure surely the necks should be sealing.

    The brass is PPU so it may be a low quality, as said I'm getting stiff bolt lift and extractor marks but I would have thought even soft brass should handle his load comfortably. I have got a batch of hornady brass left over from a couple of boxes of superformance I could try.

    The seating depth, currently I have a .1mm jump to the lands, I am wondering if this is to close and causing some preassure spike.

    My question for you is what would you try first change the brass or lower the COAL?
    If I change brass or COAL do i need to lower the charge weight and work back up and by how much?

    Thanks every one.

  2. #2
    Member
    Join Date
    May 2016
    Location
    Blenheim
    Posts
    1,156
    I would change the coal first. Although I muck around with a couple of cg's the load you are using is below what I am currently at. I too use the 140 sst; ok pill as I see it. Currently I am generating about 2600's with the sporting version of my 6.5. Coal is 2.990 but I am going to extend it to 3.1. Various forums suggest the 'variation in throat length' whilst others say '6.5 likes some jump...'. That said I am thinking older actions. I've had no issues with PPU brass, but perhaps you could weigh a selection of individual cases to see if they are the same. My 2 cents worth from an old dude with time to play round.

  3. #3
    Member
    Join Date
    Nov 2014
    Location
    Christchuch New Zealand
    Posts
    6,072
    I had a good run with Highland brass which I am informed is the same manufacturer as PPU. Mine likes 42.4gr of 2209 behind a 140gr SP so I do not think it is the charge itself. I would try seating the bullet deeper giving you a shorter OAL. I think from memory mine is about 2.9 but I will check later today.

  4. #4
    Member
    Join Date
    Dec 2013
    Location
    Tokoroa
    Posts
    1,221
    I have had a few 6.5x55's over the years I got better velocity and accuracy with 2213sc, 0.1mm is way to close to the rifling it would explain your high pressure,
    Hornady recommended C.O.A.L at 2.905" start there to get the powder charge sorted first before mucking about with the seating depth

  5. #5
    northdude
    Guest
    I'm using that brass in 3 of my 6.5s havnt had those problems and ive gone as far as 45gr using 2209 my scientific way of setting up the seating depth is start a projectile in a necksized case without a primer then put it in the rifle and close the bolt open it and take the case out put it in your press wind the seating die out and raise the ram then I wind the seater down till it touches the projectile lower the ram then wind die down 1/4 of a turn then that's it its worked in all the calibers I reload for one exeption is the m96/38s I reload for they have long throats so I seat 6.5mm of projectile into the case you can keep the case you just used for setting up/checking seating die I don't have all the indepth measurements etc just a target to show it works

  6. #6
    northdude
    Guest
    how do you know what velocity your getting
    veitnamcam likes this.

  7. #7
    Member
    Join Date
    May 2016
    Location
    Blenheim
    Posts
    1,156
    I have used the same method as Northdude and it works. Word of warning though as dumb ass me thought 'one size fits all'. Duh! Loaded a few (single figures) and they fitted my sporterised 6.5 with smooth bolt closure. Thought I would chamber one in my fully wooded/ shooting prize/ beautiful specimen and could not close the bolt. Read on an overseas forum that some "better" were refurbished at sometime. Mine could be one.
    northdude likes this.

  8. #8
    Member Danny's Avatar
    Join Date
    Aug 2013
    Location
    Central NI
    Posts
    5,084
    I'm at 46.3 using 140 and no signs of pressure although slight cratering on primer.
    This appears well out of my league I'm sorry but I'd definitely bump the projectile back by a half a mm and try that.


    Sent from my iPhone using Tapatalk
    Eastern Wander likes this.
    Dan M

  9. #9
    GWH
    GWH is offline
    Member
    Join Date
    Jul 2012
    Location
    Napier, Hawkes Bay
    Posts
    4,460
    I'm running 46.5gr of 2209 with a 143gr eldx in Lapua brass. 2780 fps from 22" T3.

    My oal is 3.203" and is off the lands.

    I'd try seating a tad deeper. Say 20 thou (.5mm) off lands and see how that goes.

    My load is reasonably accurate in my t3

    Name:  20170709_101353.jpg
Views: 693
Size:  978.7 KB but every rifle is different

  10. #10
    Member
    Join Date
    Dec 2011
    Location
    NI
    Posts
    12,732
    With my .243 I've had pressure problems PPU/Privi cases. Rem & Win are ok.

  11. #11
    Banned
    Join Date
    Mar 2016
    Location
    auckland
    Posts
    2,453
    Good tip there on OAL setting Northdude for those that don't have an OAL gauge.
    My rifles are from 20 to 40thou off lands apart from a military throated Swede which is nowhere near the lands.
    Moderate loads in all.

  12. #12
    Almost literate. veitnamcam's Avatar
    Join Date
    Dec 2011
    Location
    Nelson
    Posts
    24,964
    How far did you check your trajectory to arrive at that speed? It is possible your speed(and pressure) is a lot higher than what the book says especially if loading close to the lands.
    "Hunting and fishing" fucking over licenced firearms owners since ages ago.

    308Win One chambering to rule them all.

  13. #13
    Member
    Join Date
    May 2012
    Location
    Up north
    Posts
    245
    Thanks every one for the responses,
    sounds like the seating depth is where I should be starting, when I first setup the load i did the bullet in chamber with slight preassure and cleaning rod down barrel, and did the lose neck thing to confirm where the lands were, so I'm confident of thos measurements, just set my load up to close by the sound of it.

    I only shot to 400 to confirm that velocity but the bullet was dropping allot more than the ballistics calculator was saying for a velocity of 2700.

    I need to load some more up any way so do I need to back the load off at all seating deeper or just stick with the same and alter the seating depth.

    Also as @veitnamcam said if the preassure and velocity are higher because of close seating depth is this a better way of achieving velocity or seating deeper and using more powder? This isn't something I even new existed with reloading (I am fairly new to it) I thought seating depth only changed accuracy.

    The accuracy is spot on averaging around .75-1 inch off a good solid rest so I am hesitant to change things but I got into reloading to try get the most out of this case and I might as well be shooting the factory loads at thos velocities, I'm trying to shoot longer ranges.

    Thanks again.

  14. #14
    Member
    Join Date
    May 2012
    Location
    Up north
    Posts
    245
    Also might have to bump that cronograph up the priority list

  15. #15
    Member
    Join Date
    Feb 2012
    Location
    hastings
    Posts
    297
    Potentially so much going on there...is the zero right...are the clicks on the scope accurate...my Bushnell elite is miles out...way over 1/4 inch for each click....I start a scope by shooting a three shot at 100 yards then dialling 12moa and seeing how much the group rises. My Lee scales I used for years tuned out to be about 2 grains out as well...I'm still using cheap gear...and it makes life complicated.
