Thread: Lewis winch : gear reduction

  1. #1
    ebf
    ebf is offline
    Mushroom juice ! Hic ! ebf's Avatar
    Join Date
    Jun 2012
    Location
    Above the Hutt
    Posts
    6,872

    Lewis winch : gear reduction

    Anyone here tried their hand at making something like a Lewis chainsaw winch ?

    I've got a spare Husky 36 that would be a good candidate for this...

    Curious to see pics / designs, and hear what gear reduction you used.
    paremata likes this.
    Viva la Howa ! R.I.P. Toby | Black rifles matter... | #illegitimate_ute

  2. #2
    Member
    Join Date
    Jan 2019
    Location
    Paremata
    Posts
    792
    Have you seen this one?


  3. #3
    Caretaker
    Join Date
    Dec 2011
    Location
    Hawkes Bay
    Posts
    9,265
    I use a 4stroke water blaster motor with a “mate” post hole borer gearbox on it, the 25mm shaft easily accepts a Capstan drum

    Nice and quiet and easily snaps 500kg sash cord at just above idle

    It’s lifted many a deer 700m back up to the road. I have 3x rolls of cord at 250m per roll

    Very economical and quiet

    A big thankyou to BRADS for the gearbox

    Name:  8C1252DF-4F3A-4619-AD55-636AA5EFA530.jpeg
Views: 1001
Size:  6.42 MB



    Name:  3BF45568-F491-4EC4-9F74-F0D6AB75A2AE.jpeg
Views: 976
Size:  6.04 MB
    A big fast bullet beats a little fast bullet every time

  4. #4
    ebf
    ebf is offline
    Mushroom juice ! Hic ! ebf's Avatar
    Join Date
    Jun 2012
    Location
    Above the Hutt
    Posts
    6,872
    Found this on YouTube last night.

    https://www.youtube.com/watch?v=tS0yxsx1Ico

    Very clever - guys grafts a 1:31 worm gear onto a small chainsaw motor.
    40mm likes this.
    Viva la Howa ! R.I.P. Toby | Black rifles matter... | #illegitimate_ute

  5. #5
    Member
    Join Date
    Jan 2019
    Location
    Prebbleton (Christchurch)
    Posts
    654
    quite a few NZ jetboat guys are setting up little capstan winches. Worth a google

  6. #6
    Member
    Join Date
    Jul 2012
    Location
    Tauranga
    Posts
    2,599
    Quote Originally Posted by berg243 View Post
    we had a capstan setup at telecom for pulling smaller cables and ropes down duct lines .6.5 hp honda in a frame with a chain drive using sprockets for the reduction speed . all fitted inside a cage with a cross shaft at the end sticking out each side with 2 different sized capstans for different loads.usually had to tie it to a big truck as it could pull some big loads. have seen the honda motors setup from a factory with a capstan fitted.
    Yeah you could really tell when you had a good load on, the rope would start to sea saw.

  7. #7
    Member
    Join Date
    Aug 2012
    Location
    Christchurch
    Posts
    4,606
    I'm using this for my jetboat.

    https://www.hecanterbury.co.nz/shop/...winch/pcw3000/

    Might be worth seeing if you can replicate any specs? Or just copy 7mmsaums as that looks ideal
    Moa Hunter likes this.

  8. #8
    Member
    Join Date
    Dec 2012
    Location
    Dunedin
    Posts
    589
    About 5 years back there was a Nz made one that bolted to a saw .It was a lot better made than what is available now.From memory it had a 3 ton single line pull.I can't find any links to it now pretty sure it was on trademe for a bit around that time.
    7mmsaum and Moa Hunter like this.

  9. #9
    Caretaker
    Join Date
    Dec 2011
    Location
    Hawkes Bay
    Posts
    9,265
    The problem with running a winch off a chainsaw is the bloody noise, screaming away for ages while your trying to get a job done

    4 stroke power is just so much quieter and more comfortable for everyone involved
    rugerman, Moa Hunter and 40mm like this.
    A big fast bullet beats a little fast bullet every time

  10. #10
    Member
    Join Date
    Jun 2016
    Location
    Perth
    Posts
    72

  11. #11
    Member
    Join Date
    Feb 2016
    Location
    Stewart island / canterbury
    Posts
    9,186
    Quote Originally Posted by SkiHunt View Post
    Interesting.... Not much more than you can move by hand with a couple of pulleys though, a lot less hard work and rope cutting into your hands

  12. #12
    Member BRADS's Avatar
    Join Date
    Oct 2012
    Location
    Central Hawkes Bay
    Posts
    9,544
    Quote Originally Posted by 7mmsaum View Post
    The problem with running a winch off a chainsaw is the bloody noise, screaming away for ages while your trying to get a job done

    4 stroke power is just so much quieter and more comfortable for everyone involved
    Theres a local guy selling those old "mate" borer heads now all reconditioned and can made to fit any power head if you no anyone after one.

    Sent from my SM-G986B using Tapatalk
    7mmsaum, veitnamcam and berg243 like this.

  13. #13
    Member
    Join Date
    Jan 2012
    Location
    allover
    Posts
    433
    I have a pcw5000 and have picked up a lewis winch with a big saw engine off the ground and surprisingly it was no lighter but included the cable. If the mate gearbox proves sturdy long-term then 7mmsaums design is a winner. The going rate for a 2nd hand capstan pcw or simpson is 1.5k+ and they get snapped up fairly quick, Jet boat guys are looking to buy these new at the moment but there is supposedly no stock in the country.

    If anyone has a simple design for a sturdy lightweight land anchor I'd be interested to see

  14. #14
    Caretaker
    Join Date
    Dec 2011
    Location
    Hawkes Bay
    Posts
    9,265
    I have used a lot of Waratahs as land anchors

    Drive them in full length with a D shackle on the top of them

    Cheap easy and effective
    veitnamcam likes this.
    A big fast bullet beats a little fast bullet every time

  15. #15
    Member
    Join Date
    Aug 2012
    Location
    Christchurch
    Posts
    4,606
    Quote Originally Posted by yerimaginaryM8 View Post
    I have a pcw5000 and have picked up a lewis winch with a big saw engine off the ground and surprisingly it was no lighter but included the cable. If the mate gearbox proves sturdy long-term then 7mmsaums design is a winner. The going rate for a 2nd hand capstan pcw or simpson is 1.5k+ and they get snapped up fairly quick, Jet boat guys are looking to buy these new at the moment but there is supposedly no stock in the country.

    If anyone has a simple design for a sturdy lightweight land anchor I'd be interested to see
    This is the most simple solution I've come across. Have tried the anchor type but are hard work in rover

    https://www.peakmarine.co.nz/new-products
    7mmsaum likes this.
