Thread: Barometric pressures at altitude

  1. #1
    Member
    Join Date
    Mar 2012
    Location
    Waikato
    Posts
    2,095

    Barometric pressures at altitude

    Some measured values people might find useful for setting up drop tables. These are just from a barometer app on my phone.

    For my 7mm08 the drop at 300m is about 3cm less and the wind drift for 5m/s full crosswind is 6cm less at 1500mthan at sea level.

    I make up my chart for 500mASL and include a note with the correction for 300m at 1500m.


    Waihohonu hut
    Alt 1150m
    Temp 10.5C
    Baro 888hPa
    Wind 2m/s

    Rangipo hut
    Alt 1550m ASL
    Temp 8.8C
    Baro 841hPa
    Wind 4 m/s

    Mangaehuehu hut
    Alt 1280m ASL
    Temp 12.8C
    Baro 873 hPa
    Wind 2.5 m/s

    If someone could post measured pressures at 2000m and 2500m or a link to an online reference table that would be interesting,thanks.
    DBL likes this.

  2. #2
    Member Puffin's Avatar
    Join Date
    May 2012
    Location
    Porirua
    Posts
    1,009
    Bagheera likes this.

  3. #3
    Caretaker
    Join Date
    Dec 2011
    Location
    Hawkes Bay
    Posts
    9,265
    Altitude alone can be a very inaccurate indicator of air pressure

    Relative air pressure is what you need to focus on, measure it with a device that doesn’t convert altitude into air pressure readings

    PS: Most hunters can use an average of 28inhg and harvest a lot of deer

    Name:  7A197EAD-2741-4903-926E-BE86936CD8AB.jpeg
Views: 523
Size:  804.7 KB
    Shearer and chainsaw like this.
    A big fast bullet beats a little fast bullet every time

  4. #4
    Member
    Join Date
    Mar 2012
    Location
    Waikato
    Posts
    2,095
    Thanks @Puffin that calculator agrees with all three of my measurements closer than 5 hPa.

  5. #5
    Member
    Join Date
    Mar 2012
    Location
    Waikato
    Posts
    2,095
    Whats the device youve got in that pic Saum ?

    Im pretty sure phones will be measuring station pressure ie actual pressure on site not calculating from GPS altitude. The appis supposed to be used to track trend over time too (although ive never been patient enough to get a good trace of it).

  6. #6
    Caretaker
    Join Date
    Dec 2011
    Location
    Hawkes Bay
    Posts
    9,265
    It’s a Skywatcher Explorer 4
    Relative Baro , temp, air speed etc, metric and imperial readings
    A big fast bullet beats a little fast bullet every time

  7. #7
    Member
    Join Date
    Mar 2012
    Location
    Waikato
    Posts
    2,095
    Ok you've made me ask. Whats “relative air pressure” ? Is it density altitude, percent of sea level etc ? Where do you put it in a ballistic calculator ?

  8. #8
    Member andyanimal31's Avatar
    Join Date
    Dec 2011
    Location
    Makakahi road Raetihi
    Posts
    3,680
    Station pressure is the awnser ,
    What was the question?
    This is why I love the kestrel as it's all done for you.
    My samsung phone has station pressure sensor but no thermometer.
    You can just guess that

    Sent from my SM-G950F using Tapatalk
    Moutere likes this.
    My favorite sentences i like to hear are - I suppose so. and Send It!

  9. #9
    Member andyanimal31's Avatar
    Join Date
    Dec 2011
    Location
    Makakahi road Raetihi
    Posts
    3,680
    Quote Originally Posted by andyanimal31 View Post
    Station pressure is the awnser ,
    What was the question?
    This is why I love the kestrel as it's all done for you.
    My samsung phone has station pressure sensor but no thermometer.
    You can just guess that

    Sent from my SM-G950F using Tapatalk
    This is on the samsung

    Sent from my SM-G950F using Tapatalk
    My favorite sentences i like to hear are - I suppose so. and Send It!

  10. #10
    Caretaker
    Join Date
    Dec 2011
    Location
    Hawkes Bay
    Posts
    9,265
    There are a bunch of ways to skin this cat depending on your app and skill set

    Probably the easiest way is to measure your absolute air pressure with a barometer and enter that into your app. Often the app will then set the altitude to zero as alt is irrelevant after knowing the absolute air pressure

    Absolute air pressure is the measured air pressure right where your standing, the reading taken with an actual hand held barometer.

    Air pressure can change three times in an hour quite easily, without you even moving an inch

    At the end of the day use what works for you

    Andyanimal has extensive experience and has a system that’s reliable
    A big fast bullet beats a little fast bullet every time

  11. #11
    Member zimmer's Avatar
    Join Date
    Oct 2012
    Location
    Waikato
    Posts
    4,986
    Ultimately it is air density is what affects bullet drag.
    This article is one of the best I have read that simply explains what happens and what inputs were needed.
    Absolute air pressure is station pressure.

    https://bisonballistics.com/articles...cs-calculators
    Bagheera likes this.

  12. #12
    Member
    Join Date
    Jul 2013
    Location
    Tasman
    Posts
    1,818
    A phone with an in built barometer measures station pressure nothing else.
    With temperature and relative humidity values, density altitude can then be calculated.

  13. #13
    Member
    Join Date
    Feb 2016
    Location
    Stewart island / canterbury
    Posts
    9,186
    Watches with barometer in them are getting cheap... Used one for years, also gives you a back up compass depending on the model

  14. #14
    Member
    Join Date
    Apr 2014
    Location
    Timaru
    Posts
    965
    Use my watch for air pres(station pres) guess temp within 10 deg is close enough(but most people can guess within 5deg.) if you have correct air pres. and set humidity to 50%.

  15. #15
    Member andyanimal31's Avatar
    Join Date
    Dec 2011
    Location
    Makakahi road Raetihi
    Posts
    3,680
    Quote Originally Posted by blair993 View Post
    Use my watch for air pres(station pres) guess temp within 10 deg is close enough(but most people can guess within 5deg.) if you have correct air pres. and set humidity to 50%.
    Yep I agree that using your phone or watch for station pressure and guessing temp and 50% humidity is exactly what i would be doing if i didnt have the kestrel.
    For $400 you can get the kestrel 2700 which has every thing you need for getting an accurate elevation and wind solution out to 875yds as has the compass and applied ballistics that you can purchase custom drag curves.
    The only other good option i have used predominantly in the past is the 2500 kestrel and put that into your phone app manually which essentially gives you the same info except it's a lot slower than the 5700 and 2700.
    If you really want to do your head in start looking at spin drift, aerodynamic jump and coriolis!

    Sent from my SM-G950F using Tapatalk
    Feral likes this.
    My favorite sentences i like to hear are - I suppose so. and Send It!
